Главная Каталог продукции Toolunited 11 303-00 - End mill unspecified 52753162

52753162

Артикул: 52753162

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

24 mm

COATN Coating

APB72S

COMPC Company code

CE - Ceratizit

DC Cutting diameter

16 mm

Delivery state valid from

10/1/2021

DIN

ZYL01600105

FamilyProducts

VHM FRÄSER 3D FINISH

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

LPR Protruding length

60 mm

LS Shank length

48 mm

Name Identifying order number

52753162

OAL Overall length

108 mm

PRFA Profile included angle

25 Degree

PRFRAD2 Profile radius 2

1000 mm

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
