Главная Каталог продукции Toolunited 11 303-00 - End mill unspecified 52610161

52610161

Артикул: 52610161

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

32 mm

COATN Coating

Ti1200

COMPC Company code

CE - Ceratizit

DC Cutting diameter

16 mm

Delivery state valid from

10/1/2021

DIN

ZYL01601015

DN Neck diameter

15.5 mm

FamilyProducts

HPC VHM STIRNTORUSFRÄSER

FHA Flute helix angle

45 Degree

FHH Flute helix hand

L - Hand of helix left

GAMP Rake angle axial

7 Degree

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

LH Head length

54.75 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01601015

LPR Protruding length

60 mm

LS Shank length

48 mm

Name Identifying order number

52610161

OAL Overall length

108 mm

PRFRAD2 Profile radius 2

7.8 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
