Главная Каталог продукции Toolunited 11 303-00 - End mill unspecified 4RJ-5000T8-R090 IN05S

4RJ-5000T8-R090 IN05S

Артикул: 8453072

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12.7 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LA - Soon discontinued

DIN

SAI00800105

FamilyProducts

End mill blank

GRDMFG Grade manufacturers designation

IN05S

GRDPRIO Standard designation of the grade main application

HW-M20

HAND Cutting direction

R - Right

ID Technical product number

8453072

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAI Screw mounting ISCAR

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAI00800105

LPR Protruding length

23.45 mm

Name Identifying order number

4RJ-5000T8-R090 IN05S

OAL Overall length

31.45 mm

THSZMS Connection thread nominal size machine side

Working process

No working processes available
