Главная Каталог продукции Toolunited 11 302-06 - Spot drill 10714160

10714160

Артикул: 10714160

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COATN Coating

Ti1050

COMPC Company code

CE - Ceratizit

DC Cutting diameter minimum

16 mm

Delivery state valid from

10/1/2021

DIN

SAM01200105

FamilyProducts

VHM NC-ANBOHRER

FHH Flute helix hand

L - Hand of helix left

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-06 - Spot drill

LCF Length chip flute

20 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAM Screw mounting MAPAL

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAM01200105

LPR Protruding length

20 mm

LU Usable length

12 mm

Name Identifying order number

10714160

NOF Flute count

OAL Overall length

37.3 mm

SIG Point angle 1st step

142 Degree

Working process

No working processes available
