Главная Каталог продукции Toolunited 11 307-05 - Single row rounded end mill MRW50-S42-16-4T

MRW50-S42-16-4T

MRW50-S42-16-4T

MRW50-S42-16-4T

Kyocera
Артикул: THN06154
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
0 Degree
APMX Depth of cut maximum
8 mm
AZ Plunge depth maximum
0 mm
B3A Inscribed circle diameter Pos. A
16 mm
BD Body diameter
47.4 mm
BLDA Tool style code Position A
10
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
5.48 mm
CCONMS Connection count machine side
1
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
34 mm
DCX Cutting diameter maximum
50 mm
Delivery state valid from
5/17/2021
DIN
ZYL04200115
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
4
FamilyProducts
MRW Radius Cutter
GAMF Rake angle radial
-11 Degree
GAMP Rake angle axial
11 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN06154
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-05 - Single row rounded end mill
LF Functional length
170 mm
LH Head length
40 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0420
LOC-03 DCONMS Diameter
42 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL04200115
LPR Protruding length
45 mm
LS Shank length
130 mm
LU Usable length
30 mm
MILTTY Mill tool type ISO
N - Torus End Mill
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MRW50-S42-16-4T
OAL Overall length
170 mm
RPMX Rotational speed maximum
14800 1/min
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
1.8 kg
ZEFF Face effective cutting edge count
4
