MRF12-S16-160

Артикул: THN01634

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

15 Degree

APMX Depth of cut maximum

6 mm

B3A Inscribed circle diameter Pos. A

12 mm

BD Body diameter

11.5 mm

BLDA Tool style code Position A

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

1.6 mm

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12 mm

Delivery state valid from

5/17/2021

DIN

ZYL01600105

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

MRF Ball-nose Endmill

HAND Cutting direction

R - Right

ID Technical product number

THN01634

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

ISYC Subclass

307-13 - Die and mold end mill

LF Functional length

160 mm

LH Head length

60 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

LPR Protruding length

65 mm

LS Shank length

100 mm

LU Usable length

13 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MRF12-S16-160

OAL Overall length

160 mm

Working process

No working processes available

WT Weight of item

0.34 kg

ZEFF Face effective cutting edge count
