Главная Каталог продукции Toolunited 11 307-07 - Non-centre cutting multiple rows end mill 22J3M020020Z4R00

22J3M020020Z4R00

22J3M020020Z4R00 22J3M020020Z4R00 22J3M020020Z4R00 22J3M020020Z4R00

22J3M020020Z4R00

Ingersoll
Артикул: 3080069
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
20 mm
CCONMS Connection count machine side
2
CICT Cutting item count
6
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
ITC04000215
FamilyProducts
Extended Flute End Mill 22J3M...Z
HAND Cutting direction
R - Right
ID Technical product number
3080069
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
307-07 - Non-centre cutting multiple rows end mill
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ITC Ingersoll Tool connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
49 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ITC04000215
LPR Protruding length
45 mm
LU Usable length
30 mm
Name Identifying order number
22J3M020020Z4R00
OAL Overall length
80 mm
Working process
No working processes available
WT Weight of item
0.28 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
