50423051

Артикул: 50423051

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

1.2 mm

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

CTC3215

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

4.4 mm

EPSR Insert included angle

90 Degree

FamilyProducts

HM-FRÄSWENDEPLATTE

IC Inscribed circle diameter

9.52 mm

IH Insert hand

R - Right

Interface codes

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

L Cutting edge length

15 mm

Name Identifying order number

50423051

RE Corner radius

0.8 mm

S Insert thickness

4.76 mm

TCINS Tolerance class insert

Working process

No working processes available
