50409256
50409256
Артикул:
50409256
В наличии
Характеристики
AN Clearance angle major
15 Degree
CBMD Chip breaker manufacturers designation
-33
CECC Cutting edge condition code
S - Chamfered and rounded
COATN Coating
GM246
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
4.4 mm
EPSR Insert included angle
90 Degree
FamilyProducts
HM-FRÄSWENDEPLATTE
IC Inscribed circle diameter
9.52 mm
IH Insert hand
R - Right
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-04 - Rectangular insert
L Cutting edge length
15 mm
Name Identifying order number
50409256
RE Corner radius
4 mm
S Insert thickness
4.76 mm
TCINS Tolerance class insert
F
Working process
No working processes available
