Главная Каталог продукции Toolunited 11 202-01 - Insert, one cutting edge for grooving, screw mounting GER145-010B KW10

GER145-010B KW10

Артикул: TWE16830

В наличии

В корзину

Описание

Характеристики

ANL Clearance angle flank left hand

2 Degree

ANR Clearance angle flank right hand

2 Degree

CECC Cutting edge condition code

F - Sharpedged

COMPC Company code

KYO - Kyocera

CW Cutting width

1.45 mm

D1 Fixing hole diameter

2.7 mm

Delivery state valid from

3/16/2021

DIN

KYO-GER

EPSR Insert included angle

90 Degree

FamilyProducts

Inserts for Grooving GE

GAN Insert rake angle

25 Degree

GRDMFG Grade manufacturers designation

KW10

ID Technical product number

TWE16830

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

INSL Insert length

8.2 mm

Interface codes

J6 /

ISYC Subclass

202-01 - Insert, one cutting edge for grooving, screw mounting

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KYO-GER

Name Identifying order number

GER145-010B KW10

NOF Flute count

PFS Profile form

REL Corner radius left hand

0.1 mm

RER Corner radius right hand

0.1 mm

S Insert thickness

3 mm

S1 Insert thickness total

3.18 mm

TCE Tipped cutting edge code

W1 Insert width

8.46 mm

Working process

No working processes available

WT Weight of item

0.002 kg

Главный задний угол (AN) / Clearance angle major (AN)

0 Degree
