Главная Каталог продукции Toolunited 11 202-01 - Insert, one cutting edge for grooving, screw mounting GC08R120-005 PR1535

GC08R120-005 PR1535

Артикул: TLC19946

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

ANL Clearance angle flank left hand

2.5 Degree

ANR Clearance angle flank right hand

2.5 Degree

CECC Cutting edge condition code

F - Sharpedged

COATN Coating

MEGACOAT NANO

COMPC Company code

KYO - Kyocera

CW Cutting width

1.2 mm

D1 Fixing hole diameter

2.7 mm

Delivery state valid from

3/16/2021

DIN

KYO-GC08R

EPSR Insert included angle

90 Degree

FamilyProducts

Inserts for Grooving GC

GAN Insert rake angle

5 Degree

GRDMFG Grade manufacturers designation

PR1535

ID Technical product number

TLC19946

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

INSL Insert length

7.7 mm

Interface codes

J6 /

ISYC Subclass

202-01 - Insert, one cutting edge for grooving, screw mounting

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KYO-GC08R

Name Identifying order number

GC08R120-005 PR1535

NOF Flute count

PFS Profile form

REL Corner radius left hand

0.05 mm

RER Corner radius right hand

0.05 mm

S Insert thickness

1.2 mm

TCE Tipped cutting edge code

W1 Insert width

3.4 mm

Working process

No working processes available

WT Weight of item

0.001 kg
