Главная Каталог продукции Toolunited 11 202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth 06IR5501 PR1115

06IR5501 PR1115

Артикул: TJY18011

В наличии

В корзину

Описание

Характеристики

CECC Cutting edge condition code

E - Rounded

COATN Coating

PVD

COMPC Company code

KYO - Kyocera

CRE Spot radius

0.1 mm

D1 Fixing hole diameter

2.3 mm

Delivery state valid from

3/16/2021

DIN

KYO-06IR

EPSR Insert included angle

60 Degree

FamilyProducts

Internal Threading Inserts 06IR

GAN Insert rake angle

15 Degree

GRDMFG Grade manufacturers designation

PR1115

IC Inscribed circle diameter

3.97 mm

ID Technical product number

TJY18011

IFS Insert mounting style code

4 - Counter bore for screws with taper angle from 70° to 90°

IH Insert hand

R - Right

Interface codes

J6 /

ISYC Subclass

202-08 - Lay-down threading insert, triangle shape, three cutting edges, one tooth

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KYO-06IR

Name Identifying order number

06IR5501 PR1115

NOF Flute count

NT Tooth count

PAL Profile angle left hand

27.5 Degree

PAR Profile angle right hand

27.5 Degree

PFS Profile form

PNA Profile included angle

55 Degree

S Insert thickness

1.71 mm

S1 Insert thickness total

1.91 mm

TCE Tipped cutting edge code

THFT Thread form type

TPIN Threads per inch minimum

TPT Thread profile type

T - Partial profile

TTP Thread type

I - Internal thread

Working process

No working processes available
