50433250

Артикул: 50433250

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

20 Degree

CBMD Chip breaker manufacturers designation

-33

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

GM246

COMPC Company code

CE - Ceratizit

EPSR Insert included angle

90 Degree

FamilyProducts

HM-FRÄSWENDEPLATTE

IC Inscribed circle diameter

12.7 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

12.7 mm

Name Identifying order number

50433250

RE Corner radius

1.2 mm

S Insert thickness

3.18 mm

TCINS Tolerance class insert

Working process

No working processes available
