50405800
50405800
Артикул:
50405800
В наличии
Характеристики
AN Clearance angle major
6 Degree
BS Wiper edge length
3.65 mm
CBMD Chip breaker manufacturers designation
-M50
CECC Cutting edge condition code
E - Rounded
COATN Coating
CTP2235
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.7 mm
EPSR Insert included angle
90 Degree
FamilyProducts
HM-FRÄSWENDEPLATTE
IC Inscribed circle diameter
15.87 mm
IH Insert hand
R - Right
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-09 - Octogonal insert
L Cutting edge length
10.82 mm
Name Identifying order number
50405800
S Insert thickness
6.03 mm
TCINS Tolerance class insert
K - Cold formed
Working process
No working processes available
