Главная Каталог продукции Toolunited 11 309-02 - Turning tool for external threading KTNR3225P-22

KTNR3225P-22

KTNR3225P-22

KTNR3225P-22

Kyocera
Артикул: THC03966
В наличии
В корзину
Описание
Характеристики
A1A SKJ Cutting edge angle major Pos. A
8
A5A SKJ Gewindeart Schneidkörper Pos.A
M
A61A SKJ Thread pitch minimum
3.5 mm
BLDA SKJ Tool style code Position A
8
C8A SKJ Spitzenradius Schneidkörper Pos.A
0.48 mm
CEATC Tool cutting edge angle type code
E - Front lead angle
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
DCC Design configuration style code
S - Solid steel, no construction features
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/16/2021
DHD Drop head design
2 - Normal and overhead
DIN
VKT32250105
DIN CSW1
KYO-22ER
FamilyProducts
KYOCERA EXTERNAL THREADING TOOLHOLDER
G3A SKJ Eingeschriebener Kreis Schneidkörper Pos.A
12.7 mm
G7A SKJ Schneidkantenhöhe Schneidkörper Pos.A
4.7 mm
HAND Cutting direction
R - Right
HF Functional height
32 mm
ID Technical product number
THC03966
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-02 - Turning tool for external threading
KAPR Tool cutting edge angle
90 Degree
LF Functional length
170 mm
LH Head length
34 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
3225
LOC-03 H Shank height
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT32250105
MIID Master insert identification
22ER500ISO
Name Identifying order number
KTNR3225P-22
OAL Overall length
170 mm
SX Shank cross section shape code
02 - Square shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
30.5 mm
Working process
No working processes available
