10405080
10405080
Артикул:
10405080
В наличии
Характеристики
CCONMS Connection count machine side
1
COATN Coating
vap.
COMPC Company code
CE - Ceratizit
Delivery state valid from
10/1/2021
DIN
MKG00202085
FamilyProducts
HSS MEHRFASENSTUFENBOHRER
FHH Flute helix hand
L - Hand of helix left
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
302-02 - Step drill
LCF Length chip flute
114 mm
LOC-03 CCFMS Connection code form
20
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
MKG Morse taper
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0020
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
MKG00202085
LU Usable length
91.5 mm
Name Identifying order number
10405080
NOF Flute count
2
NOS Step count
2
OAL Overall length
212 mm
SIG Point angle 1st step
118 Degree
Working process
No working processes available
