Главная Каталог продукции Toolunited 11 302-02 - Step drill 10365120

10365120

Артикул: 10365120

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

COATN Coating

vap.

COMPC Company code

CE - Ceratizit

Delivery state valid from

10/1/2021

DIN

ZYL01350105

FamilyProducts

HSS MEHRFASENSTUFENBOHRER

FHH Flute helix hand

L - Hand of helix left

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

302-02 - Step drill

LCF Length chip flute

108 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0135

LOC-03 DCONMS Diameter

13.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01350105

LPR Protruding length

109 mm

LS Shank length

52 mm

Name Identifying order number

10365120

NOF Flute count

NOS Step count

OAL Overall length

160 mm

SIG Point angle 1st step

118 Degree

Working process

No working processes available
