Артикул:
10320050
В наличии
Характеристики
CCONMS Connection count machine side
1
COATN Coating
ohne
COMPC Company code
CE - Ceratizit
Delivery state valid from
10/1/2021
DIN
ZYL00450105
FamilyProducts
HSS MEHRFASENSTUFENBOHRER KURZ
FHH Flute helix hand
L - Hand of helix left
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
302-02 - Step drill
LCF Length chip flute
28 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0045
LOC-03 DCONMS Diameter
5.5 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00450105
LPR Protruding length
29 mm
LS Shank length
38 mm
Name Identifying order number
10320050
NOF Flute count
2
NOS Step count
2
OAL Overall length
66 mm
SIG Point angle 1st step
118 Degree
Working process
No working processes available
