Главная Каталог продукции Toolunited 11 308-04 - Shell milling cutter MSRS90200R-2-10T

MSRS90200R-2-10T

MSRS90200R-2-10T

MSRS90200R-2-10T

Kyocera
Артикул: THN01488
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A1B Cutting edge angle major Pos. B
90 Degree
A2A Clearance angle major Pos. A
11 Degree
A2B Clearance angle major Pos. B
11 Degree
B1A Cutting edge length Pos. A
18.34 mm
B1B Cutting edge length Pos. B
18.34 mm
B3A Inscribed circle diameter Pos. A
18.34 mm
B3B Inscribed circle diameter Pos. B
18.34 mm
BLDA Tool style code Position A
2
BLDB Tool style code Position B
2
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
6.35 mm
C1B Insert thickness Pos. B
6.35 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
31 mm
CICT Cutting item count
20
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
1.6 mm
D1B Corner radius Pos. B
1.6 mm
DC Cutting diameter
200 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/17/2021
DHUB Hub diameter
130 mm
DIN
FDA18751220
FamilyProducts
MSRS90 Lead Angle 0°Milling Cutter
HAND Cutting direction
R - Right
ID Technical product number
THN01488
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
308-04 - Shell milling cutter
LCCB Counterbore depth connection bore
22 mm
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
SPMT180616EN-NB4
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
KYO-SP18063N
LOC-03 CCFMS Connection code form
12
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1875
LOC-03 DCONMS Diameter
47.625 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA18751220
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MSRS90200R-2-10T
OAL Overall length
60 mm
THUB hub thickness
15 mm
Working process
No working processes available
WT Weight of item
6.6 kg
ZEFF Face effective cutting edge count
10
ZEFP Peripheral effective cutting edge count
10
