MSRS90080R-4-4T-M

MSRS90080R-4-4T-M

MSRS90080R-4-4T-M

Kyocera
Артикул: THN01455
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A1B Cutting edge angle major Pos. B
90 Degree
A2A Clearance angle major Pos. A
11 Degree
A2B Clearance angle major Pos. B
11 Degree
B1A Cutting edge length Pos. A
18.34 mm
B1B Cutting edge length Pos. B
18.34 mm
B3A Inscribed circle diameter Pos. A
18.34 mm
B3B Inscribed circle diameter Pos. B
18.34 mm
BLDA Tool style code Position A
2
BLDB Tool style code Position B
2
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
6.35 mm
C1B Insert thickness Pos. B
6.35 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
5 mm
CICT Cutting item count
16
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CWN Cutting width minimum
60 mm
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
1.6 mm
D1B Corner radius Pos. B
1.6 mm
DC Cutting diameter
80 mm
DCCB Counterbore diameter connection bore
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/17/2021
DHUB Hub diameter
70 mm
DIN
FDA02702200
FamilyProducts
MSRS90 Lead Angle 0°Milling Cutter
HAND Cutting direction
R - Right
ID Technical product number
THN01455
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
308-04 - Shell milling cutter
LCCB Counterbore depth connection bore
53 mm
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
SPMT180616EN-NB4
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
KYO-SP18063N
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0270
LOC-03 DCONMS Diameter
27 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02702200
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MSRS90080R-4-4T-M
OAL Overall length
85 mm
THUB hub thickness
11.4 mm
Working process
No working processes available
WT Weight of item
1.4 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
