MFH22-S20-03-3T
MFH22-S20-03-3T
Артикул:
THN07598
В наличии
Характеристики
A1A Cutting edge angle major Pos. A
75 Degree
A2A Clearance angle major Pos. A
0 Degree
APMX Depth of cut maximum
1 mm
AZ Plunge depth maximum
1 mm
B1A Cutting edge length Pos. A
11.9 mm
B2A Insert width Pos. A
6.2 mm
B3A Inscribed circle diameter Pos. A
6.2 mm
BD Body diameter
21 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
3.92 mm
CCONMS Connection count machine side
1
CICT Cutting item count
3
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D2A Corner chamfer length Pos. A
3.8 mm
D3A Corner chamfer angle Pos. A
6.5 Degree
DC Cutting diameter
22 mm
Delivery state valid from
5/17/2021
DIN
ZYL02000115
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
3
FamilyProducts
MFH Mini High Feed Cutter
GAMF Rake angle radial
-10 Degree
GAMP Rake angle axial
-10 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN07598
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-02 - Non-centre cutting single row V-groove end mill
KAPR Tool cutting edge angle
12 Degree
LF Functional length
130 mm
LH Head length
30 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LPR Protruding length
35 mm
LS Shank length
100 mm
LU Usable length
17 mm
MILTTY Mill tool type ISO
J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFH22-S20-03-3T
OAL Overall length
130 mm
RMPX Ramping angle maximum
1.4 Degree
RPMX Rotational speed maximum
14700 1/min
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
0.324 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
