Главная Каталог продукции Toolunited 11 307-02 - Non-centre cutting single row V-groove end mill MFH12-S12-01-3T

MFH12-S12-01-3T

Артикул: THN08246

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

75 Degree

A2A Clearance angle major Pos. A

11 Degree

APMX Depth of cut maximum

0.5 mm

AZ Plunge depth maximum

0.5 mm

B1A Cutting edge length Pos. A

6.26 mm

B2A Insert width Pos. A

4.19 mm

B3A Inscribed circle diameter Pos. A

4.19 mm

BD Body diameter

11.2 mm

BLDA Tool style code Position A

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

2.19 mm

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D2A Corner chamfer length Pos. A

2.2 mm

D3A Corner chamfer angle Pos. A

9.5 Degree

DC Cutting diameter

12 mm

Delivery state valid from

5/17/2021

DIN

ZYL01200115

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

MFH Micro High Feed Cutter

GAMF Rake angle radial

-20 Degree

GAMP Rake angle axial

5 Degree

HAND Cutting direction

R - Right

ID Technical product number

THN08246

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

ISYC Subclass

307-02 - Non-centre cutting single row V-groove end mill

KAPR Tool cutting edge angle

12 Degree

LF Functional length

80 mm

LH Head length

20 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200115

LPR Protruding length

25 mm

LS Shank length

60 mm

LU Usable length

8 mm

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MFH12-S12-01-3T

OAL Overall length

80 mm

RMPX Ramping angle maximum

2 Degree

RPMX Rotational speed maximum

14000 1/min

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.076 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
