Главная Каталог продукции Toolunited 11 307-02 - Non-centre cutting single row V-groove end mill MCSE104

MCSE104

Артикул: THC05844

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A2A Clearance angle major Pos. A

15 Degree

APMX Depth of cut maximum

6.5 mm

AZ Plunge depth maximum

1 mm

B1A Cutting edge length Pos. A

9.525 mm

B3A Inscribed circle diameter Pos. A

9.525 mm

BD Body diameter

14.6 mm

BLDA Tool style code Position A

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

2.78 mm

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.4 mm

DC Cutting diameter

16 mm

Delivery state valid from

5/17/2021

DIN

ZYL01600105

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

MCSE Chamfering Endmill

GAMF Rake angle radial

4 Degree

GAMP Rake angle axial

0 Degree

HAND Cutting direction

R - Right

ID Technical product number

THC05844

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

ISYC Subclass

307-02 - Non-centre cutting single row V-groove end mill

KAPR Tool cutting edge angle

45 Degree

LF Functional length

85 mm

LH Head length

31 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

LPR Protruding length

36 mm

LS Shank length

54 mm

LU Usable length

20 mm

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MCSE104

OAL Overall length

85 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.144 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
