Главная Каталог продукции Toolunited 11 307-02 - Non-centre cutting single row V-groove end mill 15G1Q050050Z4R01

15G1Q050050Z4R01

15G1Q050050Z4R01 15G1Q050050Z4R01 15G1Q050050Z4R01 15G1Q050050Z4R01

15G1Q050050Z4R01

Ingersoll
Артикул: 3093573
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
2.5 mm
BLDA Tool style code Position A
2
CCONMS Connection count machine side
2
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
28.2 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
50 mm
Delivery state
LA - Soon discontinued
DIN
ITC04000215
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
4
FamilyProducts
High Feed Cutter 15G1Q...Z
HAND Cutting direction
R - Right
ID Technical product number
3093573
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
307-02 - Non-centre cutting single row V-groove end mill
KAPR Tool cutting edge angle
12 Degree
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ITC Ingersoll Tool connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0490
LOC-03 DCONMS Diameter
49 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ITC04000215
LPR Protruding length
50 mm
Name Identifying order number
15G1Q050050Z4R01
OAL Overall length
85 mm
RMPX Ramping angle maximum
5.2 Degree
Working process
No working processes available
WT Weight of item
0.54 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
