Главная Каталог продукции Toolunited 11 308-01 - Face milling cutter OP2N315R00

OP2N315R00

OP2N315R00 OP2N315R00 OP2N315R00 OP2N315R00

OP2N315R00

Ingersoll
Артикул: 3029237
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
5 mm
CICT Cutting item count
20
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
315 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
328.6 mm
Delivery state
NL - Discontinued
DHUB Hub diameter
255 mm
DIN
SPK06000500
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
20
FamilyProducts
Face Mill OP2N
HAND Cutting direction
R - Right
ID Technical product number
3029237
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-01 - Face milling cutter
KAPR Tool cutting edge angle
43 Degree
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
SPK Spindle nose mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0600
LOC-03 DCONMS Diameter
60 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SPK06000500
Name Identifying order number
OP2N315R00
OAL Overall length
80 mm
Working process
No working processes available
WT Weight of item
27.74 kg
ZEFF Face effective cutting edge count
20
ZEFP Peripheral effective cutting edge count
20
