MFPN45063R-5T-M

MFPN45063R-5T-M

MFPN45063R-5T-M

Kyocera
Артикул: THN04490
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
108 Degree
A2A Clearance angle major Pos. A
0 Degree
ADJBY Adjustment property
0 - Adjustment not possible
B1A Cutting edge length Pos. A
12.38 mm
B3A Inscribed circle diameter Pos. A
17.03 mm
BD Body diameter
71 mm
BLDA Tool style code Position A
6
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
5.56 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
6 mm
CICT Cutting item count
5
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
D2A Corner chamfer length Pos. A
2 mm
D3A Corner chamfer angle Pos. A
28.7 Degree
D4A Cutting edge angle major Pos. A
43.33 Degree
D6A Wiper edge length Pos. A
2 mm
DC Cutting diameter
63 mm
DCCB Counterbore diameter connection bore
19 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
76 mm
Delivery state valid from
5/17/2021
DHUB Hub diameter
47 mm
DIN
FDA02202200
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
MFPN45 Lead Angle 45°Milling Cutter
HAND Cutting direction
R - Right
ID Technical product number
THN04490
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-01 - Face milling cutter
KAPR Tool cutting edge angle
45 Degree
LCCB Counterbore depth connection bore
8 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0220
LOC-03 DCONMS Diameter
22 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02202200
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFPN45063R-5T-M
OAL Overall length
40 mm
RPMX Rotational speed maximum
14000 1/min
THUB hub thickness
8 mm
Working process
No working processes available
WT Weight of item
0.5 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
