Главная Каталог продукции Toolunited 11 308-01 - Face milling cutter MFK080R-11-8T

MFK080R-11-8T

MFK080R-11-8T

Kyocera

Артикул: THN08050

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

108 Degree

A2A Clearance angle major Pos. A

0 Degree

ADJBY Adjustment property

0 - Adjustment not possible

B1A Cutting edge length Pos. A

11.54 mm

B3A Inscribed circle diameter Pos. A

15.875 mm

BD Body diameter

88.7 mm

BLDA Tool style code Position A

6

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

6.35 mm

CCONMS Connection count machine side

1

CDX Cutting depth maximum

6 mm

CICT Cutting item count

8

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.8 mm

D2A Corner chamfer length Pos. A

2 mm

D3A Corner chamfer angle Pos. A

4 Degree

D4A Cutting edge angle major Pos. A

36 Degree

D6A Wiper edge length Pos. A

0.9 mm

DC Cutting diameter

80 mm

DCCB Counterbore diameter connection bore

26 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

89 mm

Delivery state valid from

5/17/2021

DHUB Hub diameter

76 mm

DIN

FDA12502220

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

8

FamilyProducts

MFK Lead Angle 20°Milling Cutter

HAND Cutting direction

R - Right

ID Technical product number

THN08050

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

0

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

70 Degree

LCCB Counterbore depth connection bore

34.3 mm

LOC-03 CCFMS Connection code form

22

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

1250

LOC-03 DCONMS Diameter

31.75 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA12502220

MILTTY Mill tool type ISO

A - Face milling cutter shoulder cutter peripheral

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

MFK080R-11-8T

OAL Overall length

63 mm

RPMX Rotational speed maximum

8000 1/min

THUB hub thickness

12 mm

Working process

No working processes available

WT Weight of item

1.76 kg

ZEFF Face effective cutting edge count

8

ZEFP Peripheral effective cutting edge count

8
