Главная Каталог продукции Toolunited 11 308-01 - Face milling cutter 5N6R315R00

5N6R315R00

5N6R315R00 5N6R315R00 5N6R315R00 5N6R315R00

5N6R315R00

Ingersoll
Артикул: 3066238
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
17 Degree
B1A Cutting edge length Pos. A
12.52 mm
B2A Insert width Pos. A
15.88 mm
B3A Inscribed circle diameter Pos. A
15.88 mm
BLDA Tool style code Position A
2
C1A Insert thickness Pos. A
4.76 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
9 mm
CICT Cutting item count
18
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
315 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
333.1 mm
Delivery state
LH - Stocked
DHUB Hub diameter
220 mm
DIN
SPK06000500
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
18
FamilyProducts
Face Mill 5N6R
HAND Cutting direction
R - Right
ID Technical product number
3066238
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-01 - Face milling cutter
KAPR Tool cutting edge angle
45 Degree
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
SPK Spindle nose mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0600
LOC-03 DCONMS Diameter
60 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SPK06000500
Name Identifying order number
5N6R315R00
OAL Overall length
80 mm
Working process
No working processes available
WT Weight of item
27.67 kg
ZEFF Face effective cutting edge count
18
ZEFP Peripheral effective cutting edge count
18
