Главная Каталог продукции Toolunited 11 308-06 - Half-side slot milling cutter 4SJ6E100030F2R01

4SJ6E100030F2R01

4SJ6E100030F2R01 4SJ6E100030F2R01 4SJ6E100030F2R01 4SJ6E100030F2R01

4SJ6E100030F2R01

Ingersoll
Артикул: 3026545
В наличии
В корзину
Описание
Характеристики
BLDA Tool style code Position A
99
CCONMS Connection count machine side
1
CICT Cutting item count
6
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
100 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DHUB Hub diameter
47 mm
DIN
FDA02702200
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
6
FamilyProducts
2-Side Slot Mill 4SJ6...F/E 9 mm cutting width (right mounted)
HAND Cutting direction
R - Right
ID Technical product number
3026545
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-06 - Half-side slot milling cutter
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0270
LOC-03 DCONMS Diameter
27 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02702200
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
Name Identifying order number
4SJ6E100030F2R01
OAL Overall length
45 mm
Working process
No working processes available
WT Weight of item
0.91 kg
ZEFF Face effective cutting edge count
6
ZEFP Peripheral effective cutting edge count
6
