76127560

Артикул: 76127560

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

-TRR

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

CTCP125

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

9.12 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

90 Degree

FamilyProducts

HM-DREHWENDEPLATTE

GRDPRIO Standard designation of the grade main application

HC-P25

IC Inscribed circle diameter

25.4 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

25.4 mm

Name Identifying order number

76127560

RE Corner radius

2.4 mm

S Insert thickness

7.94 mm

TCINS Tolerance class insert

Working process

No working processes available
