Главная Каталог продукции Toolunited 11 201-02 - Square insert 70225044

70225044

Артикул: 70225044

В наличии

В корзину

Описание

Характеристики

CBMD Chip breaker manufacturers designation

-M70

CECC Cutting edge condition code

E - Rounded

COATN Coating

CTCK110

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

7.94 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

90 Degree

FamilyProducts

HM-DREHWENDEPLATTE

GRDPRIO Standard designation of the grade main application

HC-K10

IC Inscribed circle diameter

19.05 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

19.05 mm

Name Identifying order number

70225044

RE Corner radius

1.2 mm

S Insert thickness

6.35 mm

TCINS Tolerance class insert

Working process

No working processes available
