51062020
51062020
Артикул:
51062020
В наличии
Характеристики
AN Clearance angle major
20 Degree
BS Wiper edge length
2.1 mm
CECC Cutting edge condition code
S - Chamfered and rounded
COATN Coating
CTCP230
COMPC Company code
CE - Ceratizit
Delivery state valid from
10/1/2021
EPSR Insert included angle
90 Degree
FamilyProducts
HM-FRÄSWENDEPLATTE
GRD2ND Standard designation of the grade 2nd application
HC-M25
GRDPRIO Standard designation of the grade main application
HC-P30
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-02 - Square insert
L Cutting edge length
12.7 mm
Name Identifying order number
51062020
RE Corner radius
2.5 mm
S Insert thickness
3.18 mm
TCINS Tolerance class insert
K - Cold formed
Working process
No working processes available
