Главная Каталог продукции Toolunited 11 201-02 - Square insert 51010020

51010020

Артикул: 51010020

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

1.74 mm

CBMD Chip breaker manufacturers designation

-29R

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

CTCP230

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

5.5 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

90 Degree

FamilyProducts

HM-FRÄSWENDEPLATTE

GRD2ND Standard designation of the grade 2nd application

HC-M25

GRDPRIO Standard designation of the grade main application

HC-P30

IC Inscribed circle diameter

12.7 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

Name Identifying order number

51010020

RE Corner radius

1 mm

S Insert thickness

4.76 mm

TCINS Tolerance class insert

Working process

No working processes available
