Главная Каталог продукции Toolunited 11 201-02 - Square insert 50428901

50428901

Артикул: 50428901

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

BS Wiper edge length

2.2 mm

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating

TCM10

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

5.5 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

90 Degree

FamilyProducts

CERMET-FRÄSWENDEPLATTE

GRD2ND Standard designation of the grade 2nd application

HT-M10

GRDPRIO Standard designation of the grade main application

HT-P15

IC Inscribed circle diameter

12.7 mm

IH Insert hand

R - Right

Interface codes

ISISO ISO property

ISYC Subclass

201-02 - Square insert

L Cutting edge length

12.7 mm

Name Identifying order number

50428901

RE Corner radius

0.8 mm

S Insert thickness

5 mm

TCINS Tolerance class insert

Working process

No working processes available
