50428201
50428201
Артикул:
50428201
В наличии
Характеристики
AN Clearance angle major
15 Degree
BS Wiper edge length
1.74 mm
CBMD Chip breaker manufacturers designation
-R
CECC Cutting edge condition code
S - Chamfered and rounded
COATN Coating
GM43+
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
5.5 mm
EPSR Insert included angle
90 Degree
FamilyProducts
HM-FRÄSWENDEPLATTE
IC Inscribed circle diameter
12.7 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-02 - Square insert
L Cutting edge length
12.7 mm
Name Identifying order number
50428201
RE Corner radius
1 mm
S Insert thickness
4.76 mm
TCINS Tolerance class insert
H
Working process
No working processes available
