Главная Каталог продукции Toolunited 11 307-04 - T-slot end mill METS50-S32-H

METS50-S32-H

METS50-S32-H

METS50-S32-H

Kyocera
Артикул: THN02374
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A1B Cutting edge angle major Pos. B
90 Degree
A2A Clearance angle major Pos. A
15 Degree
A2B Clearance angle major Pos. B
15 Degree
APMX Depth of cut maximum
22 mm
B1A Cutting edge length Pos. A
12.7 mm
B1B Cutting edge length Pos. B
12.7 mm
B3A Inscribed circle diameter Pos. A
12.7 mm
B3B Inscribed circle diameter Pos. B
12.7 mm
BD Body diameter
46.5 mm
BLDA Tool style code Position A
2
BLDB Tool style code Position B
2
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
4.76 mm
C1B Insert thickness Pos. B
4.76 mm
CCONMS Connection count machine side
1
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
D1B Corner radius Pos. B
0.8 mm
DC Cutting diameter
50 mm
Delivery state valid from
5/17/2021
DIN
ZYL03201015
DN Neck diameter
26.5 mm
FamilyProducts
METS T-Slot Mill
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
12 Degree
HAND Cutting direction
R - Right
ID Technical product number
THN02374
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
1
ISISO B Indicator for ISO cutting plate Pos.B
1
ISYC Subclass
307-04 - T-slot end mill
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
SDMT120408E-K
LOC-02 MTP Clamping type code 1st step
S Screwed on across the bore, with counter bore
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SD1204083N
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03201015
LPR Protruding length
65 mm
LS Shank length
80 mm
LU Usable length
60 mm
MILTTY Mill tool type ISO
F - T-slot end mills
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
METS50-S32-H
OAL Overall length
140 mm
TCDCONMS ISO-tolerance class shank diameter
h7
Working process
No working processes available
WT Weight of item
0.852 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
