Главная Каталог продукции Toolunited 11 307-04 - T-slot end mill METS21-S25

METS21-S25

METS21-S25

Kyocera

Артикул: THN02300

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A1B Cutting edge angle major Pos. B

90 Degree

A2A Clearance angle major Pos. A

15 Degree

A2B Clearance angle major Pos. B

15 Degree

APMX Depth of cut maximum

9 mm

B1A Cutting edge length Pos. A

6.35 mm

B1B Cutting edge length Pos. B

6.35 mm

B3A Inscribed circle diameter Pos. A

6.35 mm

B3B Inscribed circle diameter Pos. B

6.35 mm

BD Body diameter

19.2 mm

BLDA Tool style code Position A

2

BLDB Tool style code Position B

2

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

3.18 mm

C1B Insert thickness Pos. B

3.18 mm

CCONMS Connection count machine side

1

CICT Cutting item count

2

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KYO - Kyocera

CXSC Coolant exit style code

0 - Without coolant exit

D1A Corner radius Pos. A

0.4 mm

D1B Corner radius Pos. B

0.4 mm

DC Cutting diameter

21 mm

Delivery state valid from

5/17/2021

DIN

ZYL02501005

DN Neck diameter

10.5 mm

FamilyProducts

METS T-Slot Mill

GAMF Rake angle radial

0 Degree

GAMP Rake angle axial

10 Degree

HAND Cutting direction

R - Right

ID Technical product number

THN02300

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISISO B Indicator for ISO cutting plate Pos.B

1

ISYC Subclass

307-04 - T-slot end mill

LOC-02 BI Block index

2

LOC-02 MIID Master insert identification

SDMT060304E-K

LOC-02 MTP Clamping type code 1st step

S Screwed on across the bore, with counter bore

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

SD0603043N

LOC-03 CCFMS Connection code form

10

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

25 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02501005

LPR Protruding length

34 mm

LS Shank length

80 mm

LU Usable length

29 mm

MILTTY Mill tool type ISO

F - T-slot end mills

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

METS21-S25

OAL Overall length

109 mm

TCDCONMS ISO-tolerance class shank diameter

h7

Working process

No working processes available

WT Weight of item

0.365 kg

ZEFF Face effective cutting edge count

1

ZEFP Peripheral effective cutting edge count

1
