Главная Каталог продукции Toolunited 11 307-04 - T-slot end mill 15T1J050021Z5R00

15T1J050021Z5R00

15T1J050021Z5R00 15T1J050021Z5R00 15T1J050021Z5R00 15T1J050021Z5R00

15T1J050021Z5R00

Ingersoll
Артикул: 3028715
В наличии
В корзину
Описание
Характеристики
BLDA Tool style code Position A
2
BLDB Tool style code Position B
2
CCONMS Connection count machine side
2
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
50 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
ITC05000215
FamilyProducts
T-Slot Mill 15T1J...Z
HAND Cutting direction
R - Right
ID Technical product number
3028715
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISYC Subclass
307-04 - T-slot end mill
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
572
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
IL-WSP-107
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ITC Ingersoll Tool connection
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03 DCONMS Diameter
78 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ITC05000215
MILTTY Mill tool type ISO
F - T-slot end mills
Name Identifying order number
15T1J050021Z5R00
OAL Overall length
128 mm
Working process
No working processes available
WT Weight of item
1.2 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
