Главная Каталог продукции Toolunited 11 308-02 - Shoulder milling cutter MFAH160RA-20T-M-SF

MFAH160RA-20T-M-SF

MFAH160RA-20T-M-SF

MFAH160RA-20T-M-SF

Kyocera
Артикул: THN08359
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
15 Degree
ADJBY Adjustment property
2 - Axial adjustment possible
B1A Cutting edge length Pos. A
5.6 mm
B3A Inscribed circle diameter Pos. A
6.02 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
7.9 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
4.6 mm
CICT Cutting item count
20
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D2A Corner chamfer length Pos. A
0.27 mm
D3A Corner chamfer angle Pos. A
21 Degree
D4A Cutting edge angle major Pos. A
70 Degree
D6A Wiper edge length Pos. A
0.5 mm
DC Cutting diameter
160 mm
DCCB Counterbore diameter connection bore
57 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/17/2021
DHUB Hub diameter
125 mm
DIN
FDA04001210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
20
FamilyProducts
MFAH for Aluminum Alloys Machining
HAND Cutting direction
R - Right
ID Technical product number
THN08359
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LCCB Counterbore depth connection bore
20.5 mm
LOC-03 CCFMS Connection code form
12
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
40 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA04001210
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFAH160RA-20T-M-SF
OAL Overall length
55 mm
RPMX Rotational speed maximum
8000 1/min
THUB hub thickness
20 mm
Working process
No working processes available
WT Weight of item
3.4 kg
ZEFF Face effective cutting edge count
20
ZEFP Peripheral effective cutting edge count
20
