Главная Каталог продукции Toolunited 11 308-02 - Shoulder milling cutter MFAH080RS-6T-SF

MFAH080RS-6T-SF

MFAH080RS-6T-SF

MFAH080RS-6T-SF

Kyocera
Артикул: THN08274
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
15 Degree
ADJBY Adjustment property
2 - Axial adjustment possible
B1A Cutting edge length Pos. A
5.6 mm
B3A Inscribed circle diameter Pos. A
6.02 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
7.9 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
4.6 mm
CICT Cutting item count
6
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
0 - Without coolant exit
D2A Corner chamfer length Pos. A
0.27 mm
D3A Corner chamfer angle Pos. A
21 Degree
D4A Cutting edge angle major Pos. A
70 Degree
D6A Wiper edge length Pos. A
0.5 mm
DC Cutting diameter
80 mm
DCCB Counterbore diameter connection bore
20 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/17/2021
DHUB Hub diameter
50 mm
DIN
FDA10002220
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
6
FamilyProducts
MFAH for Aluminum Alloys Machining
HAND Cutting direction
R - Right
ID Technical product number
THN08274
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LCCB Counterbore depth connection bore
16.5 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA10002220
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MFAH080RS-6T-SF
OAL Overall length
50 mm
RPMX Rotational speed maximum
14600 1/min
THUB hub thickness
22 mm
Working process
No working processes available
WT Weight of item
1.02 kg
ZEFF Face effective cutting edge count
6
ZEFP Peripheral effective cutting edge count
6
