Главная Каталог продукции Toolunited 11 308-02 - Shoulder milling cutter MEC100R-11-11T-M

MEC100R-11-11T-M

MEC100R-11-11T-M

MEC100R-11-11T-M

Kyocera
Артикул: THN08261
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
80 Degree
A2A Clearance angle major Pos. A
15 Degree
ADJBY Adjustment property
0 - Adjustment not possible
B1A Cutting edge length Pos. A
11 mm
B2A Insert width Pos. A
6.3 mm
B3A Inscribed circle diameter Pos. A
6.3 mm
BLDA Tool style code Position A
99
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
3.8 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
10 mm
CICT Cutting item count
11
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KYO - Kyocera
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
DC Cutting diameter
100 mm
DCCB Counterbore diameter connection bore
26 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/17/2021
DHUB Hub diameter
65 mm
DIN
FDA03202210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
11
FamilyProducts
MEC Lead Angle 0°Milling Cutter
HAND Cutting direction
R - Right
ID Technical product number
THN08261
Interface codes
J6 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA03202210
MILTTY Mill tool type ISO
A - Face milling cutter shoulder cutter peripheral
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
MEC100R-11-11T-M
OAL Overall length
55 mm
RPMX Rotational speed maximum
17000 1/min
THUB hub thickness
16.5 mm
Working process
No working processes available
WT Weight of item
1.7 kg
ZEFF Face effective cutting edge count
11
ZEFP Peripheral effective cutting edge count
11
