6K2V080R00
6K2V080R00
Артикул:
6K2V080R00
В наличии
Характеристики
BLDA Tool style code Position A
6
CCONMS Connection count machine side
0
CICT Cutting item count
8
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
80 mm
DCP Data chip provision
0 - Without data chip
Delivery state
NL - Discontinued
DHUB Hub diameter
70 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
8
FamilyProducts
Shoulder-Type Face Mill 6K3V
HAND Cutting direction
R - Right
Interface codes
/
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LOC-03 CZCMS Connection size code
0270
LOC-03 DCONMS Diameter
27 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
Name Identifying order number
6K2V080R00
OAL Overall length
50 mm
Working process
No working processes available
ZEFF Face effective cutting edge count
8
ZEFP Peripheral effective cutting edge count
8
