56309731
56309731
Артикул:
56309731
В наличии
Характеристики
AN Clearance angle major
15 Degree
CECC Cutting edge condition code
T - Chamfered
COATN Coating
WAN1240
COMPC Company code
CE - Ceratizit
Delivery state valid from
10/1/2021
FamilyProducts
HM-FRÄSWENDEPLATTE
IC Inscribed circle diameter
10 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-10 - Round insert
M M-dimension
10 mm
Name Identifying order number
56309731
S Insert thickness
3.18 mm
TCINS Tolerance class insert
M
Working process
No working processes available
