Артикул:
82657110
В наличии
Характеристики
BD Body diameter
32.7 mm
CCFWS Connection code form
21
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
COMPC Company code
CE - Ceratizit
CZCWS Connection size code
0110
DCLC Diameter collet length clamp
29.2 mm
DFC Functional diameter
32 mm
DIN
SZD03200285
FamilyProducts
SPANNZANGE MIT INNENVIERKANT
Interface codes
J6 /
ISYC Subclass
405-01 - Double angle collet
LDG Gauge diameter distance
2.7 mm
LFSF Distance to face
5.5 mm
LOC-01 CCFWS Connection code form
21
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0110
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01102105
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SZD Collet adapter DIN / ISO
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0320
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SZD03200285
Name Identifying order number
82657110
OAL Overall length
40 mm
SEALP Sealing
0 - Without sealing
STDLET Standard letter to the standard number
A
STDNO Standard
DIN ISO 15488
SZID Size identification
32
UNNO Unified number
4537 E
