Главная Каталог продукции Toolunited 11 303-05 - T-slot end mill 50240600

50240600

Артикул: 50240600

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

28 mm

COATN Coating

ohne

COMPC Company code

CE - Ceratizit

DC Cutting diameter

60 mm

Delivery state valid from

10/1/2021

DIN

ZYL03201005

DN Neck diameter

30 mm

FamilyProducts

HSSE T-NUTENFRÄSER

FHA Flute helix angle

10 Degree

FHH Flute helix hand

R - Hand of helix right

GAMP Rake angle axial

11 Degree

Interface codes

J6 /

ISYC Subclass

303-05 - T-slot end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03201005

LPR Protruding length

79 mm

LS Shank length

60 mm

Name Identifying order number

50240600

OAL Overall length

139 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
