16T35612TSRR000 IN30M
16T35612TSRR000 IN30M
Артикул:
8403518
В наличии
Характеристики
APMX Depth of cut maximum
12 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
35.6 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LA - Soon discontinued
DIN
SAI01200105
DN Neck diameter
18.3 mm
FamilyProducts
T-Slot blank Ø 19,8 - 35,6
GRD2ND Standard designation of the grade 2nd application
HW-K50
GRDMFG Grade manufacturers designation
IN30M
GRDPRIO Standard designation of the grade main application
HW-M40
HAND Cutting direction
R - Right
ID Technical product number
8403518
Interface codes
J6 /
ISYC Subclass
303-05 - T-slot end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAI Screw mounting ISCAR
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0120
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAI01200105
Name Identifying order number
16T35612TSRR000 IN30M
OAL Overall length
13.8 mm
THSZMS Connection thread nominal size machine side
T12
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
3
