TTEL 2020-3T20
TTEL 2020-3T20
Артикул:
2800393
В наличии
Характеристики
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CW Cutting width
2.4 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DIN
VKT20200105
DIN CSW1
IL-WSP-2592
FamilyProducts
TTER/L - long
HAND Cutting direction
L - Left
ID Technical product number
2800393
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-04 - Turning tool for OD grooving and parting
LF Functional length
125 mm
LOC-03 B Shank width
20 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
2020
LOC-03 H Shank height
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT20200105
Name Identifying order number
TTEL 2020-3T20
OAL Overall length
125 mm
SX Shank cross section shape code
01 - Square shank
Working process
No working processes available
WT Weight of item
0.34 kg
