Главная Каталог продукции Toolunited 11 309-04 - Turning tool for OD grooving and parting KGBAR2020K-16JCT

KGBAR2020K-16JCT

KGBAR2020K-16JCT

KGBAR2020K-16JCT

KGBAR2020K-16JCT

Kyocera

Артикул: THC14867

В наличии

В корзину

Описание

Характеристики

A1A SKJ Cutting edge angle major Pos. A

1

A2A SKJ Stechbreite Nennmaß Schneidkörper Pos.A

1.5 mm

BLDA SKJ Tool style code Position A

1

C5A SKJ Eckenradius rechts Schneidkörper Pos.A

0.1 mm

C6A SKJ Eckenradius links Schneidkörper Pos.A

0.1 mm

CDX Cutting depth maximum

2.5 mm

CEATC Tool cutting edge angle type code

E - Front lead angle

CEDC Cutting edge count

1

CNSC Coolant entry style code

3 - With Coolant entry, axial concentric and radial

COMPC Company code

KYO - Kyocera

CW Cutting width

2 mm

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DCC Design configuration style code

A - Solid steel, with internal coolant supply

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/16/2021

DHD Drop head design

2 - Normal and overhead

DIN

VKT20200115

DIN CSW1

KYO-GBA32R

FamilyProducts

KYOCERA EXTERNAL GROOVING TOOLHOLDER

G1A SKJ Schneidkörperlänge Schneidkörper Pos.A

16 mm

G3A SKJ Eingeschriebener Kreis Schneidkörper Pos.A

9.525 mm

HAND Cutting direction

R - Right

HF Functional height

20 mm

ID Technical product number

THC14867

Interface codes

J6 /

Interface codes CSW1

J41 /

ISYC Subclass

309-04 - Turning tool for OD grooving and parting

KAPR Tool cutting edge angle

90 Degree

LF Functional length

125 mm

LH Head length

24 mm

LOC-03 B Shank width

20 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

VKT Square mounting

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

2020

LOC-03 H Shank height

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

VKT20200115

MIID Master insert identification

GBA32R200

Name Identifying order number

KGBAR2020K-16JCT

OAL Overall length

125 mm

SX Shank cross section shape code

01 - Square shank

THSC Tool holder shape code

A - offset shank design

WF Functional width

24 mm

Working process

No working processes available
