76274318
76274318
Артикул:
76274318
В наличии
Характеристики
AN Clearance angle major
7 Degree
CBMD Chip breaker manufacturers designation
-SM
CECC Cutting edge condition code
E - Rounded
COATN Coating
CTCP115
COMPC Company code
CE - Ceratizit
D1 Fixing hole diameter
2.8 mm
Delivery state valid from
10/1/2021
EPSR Insert included angle
60 Degree
FamilyProducts
HM-DREHWENDEPLATTE
GRDPRIO Standard designation of the grade main application
HC-P15
IC Inscribed circle diameter
6.35 mm
IH Insert hand
N - Neutral
Interface codes
/
ISISO ISO property
1
ISYC Subclass
201-01 - Triangle insert
L Cutting edge length
11 mm
Name Identifying order number
76274318
RE Corner radius
0.8 mm
S Insert thickness
2.38 mm
TCINS Tolerance class insert
M
Working process
No working processes available
