Главная Каталог продукции Toolunited 11 201-01 - Triangle insert 7118520001

7118520001

Артикул: 7118520001

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

7 Degree

CECC Cutting edge condition code

F - Sharpedged

COATN Coating

CTDPS30

COMPC Company code

CE - Ceratizit

D1 Fixing hole diameter

2.5 mm

Delivery state valid from

10/1/2021

EPSR Insert included angle

60 Degree

FamilyProducts

PKD-DREHWENDEPLATTE

GRDPRIO Standard designation of the grade main application

DP-N30

IC Inscribed circle diameter

5.56 mm

IH Insert hand

N - Neutral

Interface codes

ISISO ISO property

ISYC Subclass

201-01 - Triangle insert

L Cutting edge length

9.6 mm

LE Cutting edge effective length

9.6 mm

Name Identifying order number

7118520001

NOI Insert index count

RE Corner radius

0.4 mm

S Insert thickness

2.38 mm

TCE Tipped cutting edge code

TCINS Tolerance class insert

Working process

No working processes available
